Microsurgical lymphovenous bypass of the thoracic duct

Penn surgeons have created a procedure to bypass thoracic duct occlusions.

  • April 20, 2023
Thoracic duct demonstrating blockage
Figure 1: Near complete occlusion of distal TD.

Interventional radiologists and plastic surgeons at the Penn Center for Lymphatic Disorders have developed a procedure to bypass occlusions in the lymphatic thoracic duct (TD), an advance with potentially life-saving consequences.

Although its role in well-being is substantial, the TD is only 3/16ths of an inch wide at its broadest point and is complicated by a tortuous and deep set course, characteristics that heighten the risk for obstruction, injury, and occlusion.

The cause of TD occlusion may be traumatic, iatrogenic, or disease-related (e.g., malignancy, sarcoidosis). Occlusion is associated with the accumulation of chyle, a triglyceride-rich fluid, and its leakage into the thoracic cavity and surrounding tissues. Chief among the complications of TD occlusion are recalcitrant chylous pleural effusion, chylopericardium, metabolic derangement, chylous ascites, generalized lymphedema, and other morbidities.

In affected individuals, untreated occlusion has been associated with a mortality of 10%–50%.

Treatment

Definitive management of TD occlusion is difficult and rarely curative. Conservative management ranges from dietary adjustments to pharmacological treatment.

Approaches for advanced disease have included angioplasty and minimally invasive procedures for ligation, embolization, and disruption. Although beneficial, these measures are limited in scope, application, and therapeutic success.

Inguinal lymph nodes with arrows indicating access to thoracic duct
Figure 2: Inguinal lymph nodes for TD access. Sample nodes indicated by red arrows; cannulation indicated by green arrow.

The treatment paradigm for TD occlusion is beginning to change, however, with recent advances in microsurgery and lymphatic visualization at the Penn Center for Lymphatic Disorders.

Lymphangiography-guided TD lymphovenous bypass, an intervention developed at the Center, now permits IR specialists and plastic surgeons to identify the locus of occlusion and re-establish normal outflow of lymphatic fluid via a bypass between the TD and the jugular vein.

The benefits of this new procedure are particularly relevant to the treatment of adults with refractory occlusion of the TD.

Case study

Thoracic duct and lymphatic structures
Figure 3: Cisterna chyli (green arrow) and proximal TD (red arrows).

Mr. W, a 61-year-old male with a history of Noonan’s syndrome, pulmonary lymphangiectasias, chylothorax, and oxygen dependency was referred to the Penn Center for Lymphatic Disorders following an acute episode of painful swelling and edema involving his left shoulder and axilla with neuropathy and weakness of the left arm. Lymphangiography was significant for distal TD occlusion at the level of the left subclavian vein (Figure 1).

Mr. W was deemed a candidate for TD bypass performed jointly between IR and plastic surgery and agreed to have the procedure after a consultation to explain its potential risks and benefits.

Location of thoracic duct indicated by arrows, clamps
Figure 4: TD localization in operative field relative to a microvascular clamp.

At surgery, a thoracic duct cannulation was performed via bilateral ultrasound-guided inguinal lymph node puncture (Figure 2). Lipiodol was then infused and intermittent fluoroscopy was used to identify intra-abdominal lymphatics and the cisterna chyli (Figure 3). Following cannulation of the TD with a microcatheter and guide wire, selective lymphangiography was conducted to advance upon the occlusion.

Surgical field with legends
Figure 5: Surgical field after bypass.

A neck dissection took place at this point and fluoroscopy was employed to aid in identifying the TD in the operative field relative to nearby surgical retractors (Figure 4).

Once identified, the TD was divided proximal to the obstruction, and a microvascular anastomosis was performed between the TD and the external jugular vein (Figure 5). The patency of this procedure was then confirmed (Figure 6).

Confirmation of patent anastomosis
Figure 6: Confirmation of patent anastomosis.

Following the bypass, Mr. W had total resolution of chylothorax and edema and was no longer oxygen dependent from a respiratory standpoint. He was discharged from the hospital on the day following his procedure and had an uneventful recovery thereafter.

About the Penn Center for Lymphatic Disorders

The Penn Center for Lymphatic Disorders, led by Director Maxim Itkin, MD, includes experts in the diagnosis, treatment, and research of lymphatic disorders.

Members of the team often collaborate to provide you with the highest level of patient care.

A national leader in research, education, and patient care, Penn Interventional Radiology is one of the oldest and largest IR programs in the United States. In addition to performing more than 12,000 procedures annually, Penn Interventional Radiology has an inpatient admitting service, inpatient consult service, and daily outpatient consultation and follow-up clinic.

Referring providers can contact a Lymphatic coordinator at 215-662-7892 or email at PennLymphatic@pennmedicine.upenn.edu.
